Flexible handling equipment for stores and factories

Our KBK stacker cranes make it possible to complete all storage and handling tasks in one operating cycle without the need for ladders, order-picking trolleys or similar equipment. Unit loads, containers or pallets weighing up to 500 kg can be safely and reliably transported, sorted and stored.

Combination of KBK double-girder suspension crane and special stacker trolley
Load handling attachments to match the load – forks, prongs, grippers and other attachments can be supplied

Product information

High flexibility

Loads are precisely picked up and guided
Simple manual crane and trolley travel
Can be turned over a range of 360°
Unit loads, containers and pallets weighing up to 500 kg can be transported, sorted and stored with ease

A KBK stacker crane mainly consists of a KBK double-girder suspension crane combined with a special stacker trolley and a load handling attachment.

Stacker trolley selection

table Stacker trolley crane data

Stacker trolley selection table	b [mm]	Size	H [mm]	T [mm]	KBK	lHT [mm]	lKr [mm]	lW KBK II-L [mm]	lW KBK II [mm]
80	900	2	4110	3420	II-L	5000	4500	4000	6000
-	-	-	-	-	II	6000	5500	3500	6000
-	1200	3	5110	4420	II-L	5000	4500	3000	5000
-	-	-	-	-	II	6000	5500	3000	5000
100	800	2	4110	3420	II-L	5000	4500	3500	6000
-	1000	3	5110	4420	II-lL	5000	4000	3000	5000
1000	800	3	5110	4420	II-L	5000	4500	3000	5000
125	700	2	4110	3420	II-L	5000	4500	3000	5000
-	-	-	-	-	II	6000	5500	3500	5500
900	700	2	5110	4420	II-L	5000	4500	3000	4500
-	-	-	-	-	II	6000	5500	3000	4500
160	550	2	4110	3420	II-L	5000	4500	3000	5000
-	-	-	-	-	II	6000	5500	3000	5000
800	550	3	5110	4420	II-L	5000	4500	2500	4000
-	-	-	-	-	II	6000	5500	2500	4000
200	480	2	4110	3420	II-L	5000	4500	2500	4500
-	-	-	-	-	II	6000	5500	2500	4500
650	480	3	5110	4420	II-L	5000	4500	2000	4000
-	-	-	-	-	II	6000	5500	2000	4000
250	400	2	4110	3420	II-L	5000	4500	2500	4500
-	-	-	-	-	II	6000	5500	2500	4000
600	400	3	5110	4420	II-L	5000	4500	2000	4000
-	-	-	-	-	II	6000	5500	2000	3500
315	370	2	4110	3420	II-L	4500	4000	2000	4000
-	-	-	-	-	II	5000	4500	2000	3500
600	370	3	5110	4150	II-L	4500	4000	1500	4000
-	-	-	-	-	II	5500	5000	1500	3500
400	350	2	4110	3420	II-L	4500	4000	1500¹	4000¹
-	-	-	-	-	II	5000	4500	1500¹	3500¹
600	350	3	5110	4150	II-L	4000	3500	1500¹	3500¹
-	-	-	-	-	II	5000	4500	1500¹	3000¹
500	300	2	4110	3420	II-L	3500	3000	-	3500¹
-	-	-	-	-	II	4500	4000	-	3500¹
600	300	3	5110	4150	II	4500	4000	-	3000¹

2 x double trolley at each end of the crane for IHT > IKR + 240 mm. Dimension h3 increases by + 15mm.

b = Load center distance

H = Unit height

T = Fork lifting height

IHT = Crane girder length

LKr = Crane span dimension

lw = Distance between supports

Size	Crab span dimension lKa and eKa1 [mm]	Xmax [mm]	c [mm]	d [mm]	f²⁾ [mm]	Max. lifting speed [mm]	Weight for max. H [kg]
2	800	1000	650	160	135	8.0	300
3	1000	1000	650	80	80	85	400
-	-	-	920	-	-	-	-

2) Dimension f for pivot center

KBK stacker cranes

Product information

High flexibility

Technical data
