KBK Overhung and Extending Cranes in India

Large overhang — fixed or flexible, your choice

Sometimes you need to move loads beyond the crane runway — and that's exactly where our overhung and extending cranes from the KBK light crane system shine. They give you more room to work with and help you make the most of every bit of available space.

Here's what we offer to meet your specific needs:

Overhung cranes — fitted with crane girders that reach out beyond the width of the crane runway, giving you extra coverage where you need it most
Extending cranes — made up of a fixed section and a movable crane section that can extend in both directions for maximum flexibility
Extended crane girders — can reach up to 2,500 mm beyond the runway span, opening up even more working area

Product information

Overhung bridge cranes

Maximum permissible overhang dimensions vary depending on the profile and crane type — and are also influenced by the payload

Additional length of the girder l_A [mm]

Type	KBK I	KBK II-L	KBK III
Single-girder suspension crane	-	1,500	1,800
Double-girder suspension crane	1,600	2,300	2,500

Extending cranes

Maximum permissible overhang dimensions vary depending on the profile and crane type — and are also influenced by the payload

Additional extension length I_A1 max [mm]

Type	KBK II-L	KBK II
A 1/1	1,500	1,800
B 2/1	1,500	2,000
B 2/2	2,300	2,500
